Binding: https://dicom.nema.org/medical/dicom/current/output/chtml/part16/sect_CID_33.html ( preferred )
Binding: https://terminology.uzis.cz/ValueSet/mkn-10 ( required )
http://dicom.nema.org/resources/ontology/DCM
version 2022.4.20221006
| Code | Display | Definition |
AR
|
Autorefraction | An acquisition device, process or method that measures autorefraction. |
BI
|
Biomagnetic Imaging | An acquisition device, process or method that performs biomagnetic imaging. |
BMD
|
Bone Mineral Densitometry | An acquisition device, process or method that performs bone mineral densitometry by X-Ray, including dual-energy X-Ray absorptiometry (DXA) and morphometric X-Ray absorptiometry (MXA). |
CR
|
Computed Radiography | An acquisition device, process or method that performs computed radiography. |
CT
|
Computed Tomography | An acquisition device, process or method that performs computed tomography. |
DMS
|
Dermoscopy | An acquisition device, process or method that performs imaging of the surface of the skin using epiluminescence microscopy. |
DG
|
Diaphanography | An acquisition device, process or method that performs diaphanography. |
DX
|
Digital Radiography | An acquisition device, process or method that performs digital radiography. |
ES
|
Endoscopy | An acquisition device, process or method that records images during endoscopy. |
XC
|
External-camera Photography | An acquisition device, process or method that performs photography with an external camera. |
GM
|
General Microscopy | An acquisition device, process or method that performs general microscopy. |
IO
|
Intra-oral Radiography | An acquisition device, process or method that performs intra-oral radiography. |
IVOCT
|
Intravascular Optical Coherence Tomography | An acquisition device, process or method that performs intravascular optical coherence tomography |
IVUS
|
Intravascular Ultrasound | An acquisition device, process or method that performs intravascular ultrasound. |
KER
|
Keratometry | An acquisition device, process or method that performs keratometry. |
LS
|
Laser surface scan | An acquisition device, process or method that performs laser surface scanning. |
LEN
|
Lensometry | An acquisition device, process or method that performs lensometry. |
MR
|
Magnetic Resonance | An acquisition device, process or method that performs magnetic resonance imaging. |
MG
|
Mammography | An acquisition device, process or method that performs mammography. |
NM
|
Nuclear Medicine | An acquisition device, process or method that performs nuclear medicine imaging. |
OAM
|
Ophthalmic Axial Measurements | An acquisition device, process or method that measures the axial length of the eye. |
OPM
|
Ophthalmic Mapping | An acquisition device, process or method that measures corneal topography, corneal or retinal thickness, and other similar parameters that are typically displayed as maps. |
OP
|
Ophthalmic Photography | An acquisition device, process or method that performs ophthalmic photography. |
OPT
|
Ophthalmic Tomography | An acquisition device, process or method that performs tomography of the eye that is based on light and optical principles. Tomography based on other principles, such as ultrasound, is excluded. |
OPTBSV
|
Ophthalmic Tomography B-scan Volume Analysis | An acquisition device, process or method that performs B-scan volume analysis of tomography images of the eye based on light and optical principles. Tomography based on other principles, such as ultrasound, is excluded. |
OPTENF
|
Ophthalmic Tomography En Face | An acquisition device, process or method that creates en face tomography images of the eye based on light and optical principles. Tomography based on other principles, such as ultrasound, is excluded. |
OPV
|
Ophthalmic Visual Field | An acquisition device, process or method that measures visual fields and perform visual perimetry. |
OCT
|
Optical Coherence Tomography | An acquisition device, process or method that uses an interferometric, non-invasive optical tomographic technique to image 2D slices and 3D volumes of tissue using visible and near visible frequencies. |
OSS
|
Optical Surface Scanner | An acquisition device, process or method that performs optical surface scanning. |
PX
|
Panoramic X-Ray | An acquisition device, process or method that performs panoramic X-Rays. |
PT
|
Positron emission tomography | An acquisition device, process or method that performs positron emission tomography (PET). |
RF
|
Radiofluoroscopy | An acquisition device, process or method that performs radiofluoroscopy. |
RG
|
Radiographic imaging | An acquisition device, process or method that performs radiographic imaging (conventional film/screen). |
RTIMAGE
|
RT Image | An acquisition device, process or method that performs radiotherapy imaging; includes portal imaging. |
SM
|
Slide Microscopy | An acquisition device, process or method that performs slide microscopy. |
SRF
|
Subjective Refraction | An acquisition device, process or method that records subjective refraction. |
TG
|
Thermography | An acquisition device, process or method that performs thermography. |
US
|
Ultrasound | An acquisition device, process or method that performs ultrasound. |
BDUS
|
Ultrasound Bone Densitometry | An acquisition device, process or method that performs ultrasound bone densitometry. |
VA
|
Visual Acuity | An acquisition device, process or method that measures visual acuity. |
XA
|
X-Ray Angiography | An acquisition device, process or method that performs X-Ray angiography. |
http://unitsofmeasure.org
| Code | Display |
| mGy.cm | mGy.cm |
http://unitsofmeasure.org
| Code | Display |
| Sv | Sv |
| mSv | mSv |
http://unitsofmeasure.org
| Code | Display |
| Gy.m2 | Gy.m2 |
| mGy.cm2 | mGy.cm2 |
Links: Table of Contents | QA Report
( preferred to
https://dicom.nema.org/medical/dicom/current/output/chtml/part16/sect_CID_33.html
)
( required to
https://terminology.uzis.cz/ValueSet/mkn-10
)
( required to
https://terminology.uzis.cz/ValueSet/mkn-10
)
Binding: https://terminology.uzis.cz/ValueSet/mkn-10 ( required )
( extensible to
http://www.rsna.org/RadLex_Playbook.aspx
)
( extensible to
http://dicom.nema.org/medical/dicom/current/output/chtml/part04/sect_B.5.html#table_B.5-1
)
Binding: http://www.rsna.org/RadLex_Playbook.aspx ( extensible ) : The performed procedure type.
Binding: http://dicom.nema.org/medical/dicom/current/output/chtml/part04/sect_B.5.html#table_B.5-1 ( extensible ) : The sopClass for the instance.
Binding: http://www.rsna.org/RadLex_Playbook.aspx ( extensible ) : The performed procedure type.
| Obligations | Actor |
| SHOULD : populate-if-known | Creator-L2 |
| SHOULD : populate-if-known | Creator-L3 |
| SHOULD : display | Consumer-L2 |
| SHOULD : display | Consumer-L3 |
