QR Code Generation

Generating a QR Code

This page is a step-by-step, implementer-facing walkthrough of how a signed health certificate becomes a QR code on a piece of paper or a phone screen, and how a verifier turns that QR code back into trustworthy data.

The container, the signature and the transport encoding are the same for every GDHCN trust domain, and are specified normatively in the HCERT Specification. What changes from one use case to the next is only the payload: which logical model goes inside the hcert claim, and under which subclaim. Everything after that choice is mechanical.

Where this page and the HCERT Specification appear to differ, the HCERT Specification is authoritative.

1. The pipeline at a glance

   Step 1  Select payload type              DVC, for this walkthrough
   Step 2  Assemble payload                 { "n": ..., "dob": ..., "vx": {...} }
   Step 3  Wrap in CWT claim set            { 1: iss, 6: iat, 4: exp, -260: { -6: payload } }
   Step 4  Serialise as CBOR                binary
   Step 5  Sign as COSE_Sign1 (ES256)       binary, tag 18
   Step 6  Compress with ZLIB/Deflate       binary
   Step 7  Encode as Base45                 ASCII
   Step 8  Prefix context identifier        "HC1:" + ASCII
   Step 9  Render QR (Alphanumeric, EC Q)   image

Steps 3 to 9 never vary with the payload. A verifier runs the same list upwards.

2. Step 1 — Select the payload type

​A payload is identified by a subclaim inside the hcert claim (-260). The subclaims, and the logical model each one carries, are enumerated in the HCert logical model; section 3.2.7.1 of the HCERT Specification is authoritative for which are assigned. The registered trust domains are listed in the GDHCN Trust Domain value set and described under Trust Domains.

Two things are worth knowing before picking a number. Subclaims 0 and above are reserved by WHO and are allocated together with a trust domain, through the GDHCN Secretariat. Subclaims that are negative integers are the development range and are free to use, so an implementation using one is a pilot or a development deployment and the number is not guaranteed to be stable.

Section 3.2.7 of the specification allows several types of health certificate to exist under the hcert claim. Carrying exactly one is an implementation choice, not a constraint of the container, and it is the choice made throughout this page.

For this walkthrough the payload is a DVC — a Digital Vaccine Certificate — carried under subclaim -6. The steps below are the steps for that payload. A different payload changes only Step 2; Steps 3 to 9 are identical.

3. Step 2 — Assemble the payload

Populate the logical model for the payload type you selected. For a DVC that is DVCMinPreQual, whose vaccine details are DVCMinVaccineDetailsPreQual. Follow those definitions for the element list, cardinalities and bindings rather than any copy of them.

DVCMinPreQual is the concrete model: its parent DVCMin is abstract, as is DVCMinVaccineDetails, so neither can be instantiated directly.

The element names are two and three characters long because every byte is paid for twice — once in the CBOR encoding and again in the QR's module count.

Four points about using the model are not apparent from the StructureDefinition and are worth stating here:

• vx is 1..1. One DVC documents one immunization event. A visit at which two vaccines are administered produces two certificates and two QR codes.
• At least one of is or cn must be present — the must-have-issuer-or-clinician-name invariant.
• id is optional precisely because many certificate subjects have no identification document. A newborn is the obvious case; gn carries the parent or guardian instead.
• vp has a required binding to the WHO PreQual product identifiers, so the administered product must be resolved in the PreQual vaccine database and that identifier used. A clinical code for the vaccine type will not satisfy it.

4. Step 3 — Build the CWT claim set

Place the payload under its subclaim, inside the hcert claim, inside a CWT claim set — see that model for the claim keys and types, and section 3.2 of the specification for their normative definitions.

exp deserves attention because it is the only revocation mechanism this specification offers: certificates cannot be reliably revoked once issued, so the validity period must be chosen to bound the damage from a compromised key, balanced against the holder's ability to come back for a reissue. It must not exceed the DSC's own validity period, and iat must not predate it. See section 6.1.

5. Step 4 — Serialise as CBOR

Encode the claim set as CBOR (RFC 7049). The JSON shown on this page and in the logical models is schema notation only — the wire format is CBOR, and an implementation need never produce the JSON form at all.

Strings SHOULD be NFC-normalised. Decoders SHOULD be permissive about input that is not.

6. Step 5 — Sign as a COSE_Sign1

Wrap the CBOR payload in a single-signer COSE structure (RFC 8152), CBOR tag 18, with alg (label 1) and kid (label 4) in the protected header.

ES256 is the primary algorithm (alg -7) and PS256 the secondary (-37). Both MUST be implemented even though only one signs any given certificate; the secondary exists so that a break in the primary does not strand the whole network. kid MAY instead sit in the unprotected header, and verifiers MUST accept both placements — but when it appears in both, the protected one wins.

Deriving the kid: take the DER encoding of the DSC and use the first 8 bytes of its SHA-256 fingerprint. Because it is truncated, kid is not unique, so a verifier that finds several DSCs with the same kid MUST try all of them. kid is not security-critical; it is a lookup hint.

Computing the signature: build the Sig_structure

Sig_structure = [ "Signature1", protected_header_bstr, external_aad (empty), payload ]

serialise it as CBOR, and sign those bytes. For ES256 the COSE signature value is the fixed-width concatenation r || s, 32 bytes each — not the ASN.1 DER encoding that most crypto libraries return by default. Converting between the two is the single most common interoperability bug in HCERT implementations.

The resulting structure is 18([protected, unprotected, payload, signature]).

7. Step 6 — Compress

Compress the COSE structure with ZLIB (RFC 1950) using Deflate (RFC 1951). Compression comes after signing, so the verifier decompresses before it verifies.

8. Step 7 — Encode as Base45

Encode the compressed bytes with Base45. Base45 exists for one reason: its 45-character alphabet is exactly the QR Alphanumeric character set, which stores data far more densely than byte mode.

9. Step 8 — Prefix the context identifier

Prefix the Base45 string with HC1:. Verifiers use this to recognise what they have scanned and which decoding scheme to apply. A future backwards-incompatible revision will use a new identifier, incrementing through [1-9] and then [A-Z].

10. Step 9 — Render the QR code

If you are printing below 300 dpi, make sure each module is rendered as an exact square. Non-proportional scaling turns modules into rectangles and is a frequent cause of certificates that scan on screen but not on paper.

11. Verifying: the same steps upwards

1. Confirm the HC1: prefix and strip it.
2. Base45-decode, then ZLIB-decompress.
3. Parse the COSE_Sign1 and read alg and kid from the protected header.
4. Validate the input before trusting it. Parsing the protected header necessarily happens before signature verification, which makes it an attack surface; check types and lengths defensively. See section 6.3.
5. Look the kid up on the trust list, retrieving every DSC that matches.
6. Rebuild the Sig_structure and verify the signature against each candidate DSC until one succeeds. Verify the signature before processing the payload.
7. Decode the CBOR payload and check exp and iat against the current time.
8. Read the hcert claim, dispatch on the subclaim to the right logical model, and only then apply business rules.

The Extended Key Usage identifiers in Appendix A.2 are inherited from the EU DCC and cover test, vaccination and recovery. They have not been applied to the payload types introduced since, and there is no mapping from the newer subclaims to a key usage, so a verifier has nothing to check them against for a DVC.

12. Worked example — a newborn birth dose DVC

12.1 Scenario

A family from the Lao People's Democratic Republic is visiting relatives abroad when the mother delivers. The newborn receives the routine birth-dose vaccinations of the host country's national childhood immunization schedule before discharge. The clinic records the doses and issues a signed certificate; the family has one shared phone between them, so the clinic prints a paper card with the QR code and offers digital delivery as an option.

This drives the design decisions directly:

• A DVC rather than an ICVP. Hepatitis B and BCG are routine schedule vaccines, not International Health Regulations entry requirements.
• Data in the QR rather than behind a link. The certificate has to verify at a rural clinic back home, on paper, with no reliable connectivity.
• Two certificates. vx is 1..1, so the birth visit yields one certificate per vaccine.
• No id, but a gn. The newborn has no identification document. The guardian element carries the mother's name instead.
• Nationality and issuer differ. nt is the infant's nationality (LAO); the issuer is the country whose clinic administered the dose. This separation is exactly what the model is for.

12.2 Host-country schedule

Thailand's Expanded Programme on Immunization gives two vaccines at birth: BCG as soon as possible after birth, and the first dose of hepatitis B vaccine within 24 hours of birth. The DTP-HepB and OPV series begin later, at 2, 4 and 6 months. A birth visit in Thailand therefore produces exactly the two certificates modelled here.

Implementers should confirm the current schedule against the national authority before relying on it; schedules are revised.

12.3 Issuer

The example is issued by GDHCN DEV participant XXR, not by any Member State. GDHCN participant codes are ISO 3166-1 alpha-3, while the CWT iss claim and the X.509 country attribute take the alpha-2 form — here XR, matching the C=XR attribute of the Document Signing Certificate subject.

Signing uses a key whose public key is onboarded to the GDHCN DEV trust network, so the example verifies against the DEV trust list. The private key is held in the build environment and never enters this repository; only the DSC, the SCA, the QR images and the HC1: strings are published.

Because iat must fall inside the DSC validity period and exp must not exceed it, the scenario dates sit inside the window of the onboarded DEV certificate.

12.4 The payload

Hepatitis B birth dose, hcert subclaim -6, shown in JSON notation. vp carries the PreQual product identifier of the product actually administered:

{
  "n":   "Chanthala SOUVANNALATH",
  "dob": "2026-10-21",
  "s":   "female",
  "nt":  "LAO",
  "gn":  "Mali SOUVANNALATH",
  "vx": {
    "vp": "a3K3X000006MiiXUAS",
    "dv": "2026-10-21",
    "cn": "Dr Pimchanok WATTANA",
    "is": "org-xxr-provincial-hospital",
    "bo": "HEPB-2026-0914"
  },
  "v": "1.0.0"
}

a3K3X000006MiiXUAS is Hepatitis B Vaccine (rDNA) (Paediatric) (FVP-P-132) in the WHO PreQual product identifiers. The BCG certificate is identical but for vp, which carries a3K3X000006MiiCUAS, BCG Vaccine (FVP-P-73), and its batch number.

Wrapped in the CWT claim set:

{
  "1":    "XR",
  "6":    1792657800,
  "4":    1824193800,
  "-260": { "-6": { "...": "the payload above" } }
}

12.5 Size at each stage

For the hepatitis B certificate:

The signature and its headers account for 85 of the 307 bytes — on payloads this small, the cryptography costs more than the clinical data. This is why the minimal models use two-character element names, and why a payload much larger than this does not belong in a QR code at all.

12.6 The certificates

Hepatitis B birth dose:

HC1:NCFOXN%TSMAHN-HHPC*8W$BM70GZW8WI47X5JU9V21HJI.OR.6J:X90$TZIPAN9I6TSQLMN2SRPOK62YU%E6SOEGW2Z0W/TO+4W3R3ZP3XQ7KUHMQQTOE2QERM2ZGA2:UG%UBPISWUO FFPEUCAQZ4K%I7YV4SVO*I1R5LK90DQK7E$BESW6846OVQICMKR6PK96M53A5/41B$P6 0JIIO*LM4UJH2/JT0DJ$JAGU09VCRCKCWC.XI5TBC+J$ZIMOBKEALOB3YIX1JM7JZIJXUK0HIQVBPEB:CJZTAI8A+BDWZD$BCTD0D4OZFJ3JKJMOZD5+B9$/G547Z2ETZVJFD-ST53VMK9E/AUJ6R9KFAQB+RL7JYX69$1K-PF:E+7AYCTGARL6KGND1K6CPFT*P-8AHFSA16U9FS34:TG/0E  6$TP*705SS44

BCG, the second certificate from the same visit:

HC1:NCFOXN%TSMAHN-HHPC*8W$BM70GZW8WI4%%5JU9V21HJI.OR.6J:X90$TZIPAN9I6TSQLMN2SRPOK62YU%E6SOEGW2Z0W/TO+4W3R3ZP3XQ7KUHMQQTOE2QERM2ZGA2:UG%UBPISWUO FFPEUCAQZ4K%I7YV4SVO*I1R5LK99AQ7LED9RNF66J6QW6:9631A*2QYDEUGAEHP8X9HSRH8KE62.13%USNCTZXIK/IL-A9AD.PD0DJGDBAB4X3C+1MRCA0ZKI8AZ3CYIJ*ZJFDJ0UJM2C8BI/NI6SI1-ACYI0+TKQ3200M:C IJM5Q52IHJP7NVQ794S8E41F.520NRYE2.JDAOSZFZNM*SJ7ONT5DE*VMKL$ASR%514QW*PA4DOQF%MV9CUYMDO:0VWKY4M.QPYI4I$U*.885E L1JJBHA5T B961BC0/:E

Both certificates carry the key identifier kW/6VnwPRKI= (hex 916ffa567c0f44a2).

To verify them, resolve that kid against the GDHCN trust list rather than against any copy of the certificate shipped beside the QR code. The DID trust list endpoints for the development, user-acceptance testing and production environments are listed under Trustlist Distribution Endpoints; this example is issued in DEV, so its Document Signing Certificate is on the DEV trust list. Fetching the signing certificate from the trust list is the verification path the specification defines, and the only one that tells a verifier the key is still trusted — a certificate distributed alongside the certificate it signed proves nothing about that.
