Resource Profile: Wof Connect Economy Organization

Usages:

• This Profile is not used by any profiles in this Implementation Guide

You can also check for usages in the FHIR IG Statistics

Formal Views of Profile Content

Description of Profiles, Differentials, Snapshots and how the different presentations work.

• Key Elements Table
• Differential Table
• Snapshot Table
• Statistics/References
• All

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Organization	C	0..*	Organization	A grouping of people or organizations with a common purpose Constraints: org-1
id	Σ	1..1	id	Logical id of this artifact
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
active	?!Σ	0..1	boolean	Whether the organization's record is still in active use
Documentation for this format

Constraints

Id	Grade	Path(s)	Description	Expression
dom-2	error	Organization	If the resource is contained in another resource, it SHALL NOT contain nested Resources	contained.contained.empty()
dom-3	error	Organization	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource	contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Organization	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated	contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Organization	If a resource is contained in another resource, it SHALL NOT have a security label	contained.meta.security.empty()
dom-6	best practice	Organization	A resource should have narrative for robust management	text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children	hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both	extension.exists() != value.exists()
org-1	error	Organization	The organization SHALL at least have a name or an identifier, and possibly more than one	(identifier.count() + name.count()) > 0

This structure is derived from Organization

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Organization		0..*	Organization	A grouping of people or organizations with a common purpose
id		1..1	id	Logical id of this artifact
meta
source		1..1	uri	Identifies where the resource comes from
profile		1..*	canonical(StructureDefinition)	Profiles this resource claims to conform to
Documentation for this format

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Organization	C	0..*	Organization	A grouping of people or organizations with a common purpose Constraints: org-1
id	Σ	1..1	id	Logical id of this artifact
meta	Σ	0..1	Meta	Metadata about the resource
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
versionId	Σ	0..1	id	Version specific identifier
lastUpdated	Σ	0..1	instant	When the resource version last changed
source	Σ	1..1	uri	Identifies where the resource comes from
profile	Σ	1..*	canonical(StructureDefinition)	Profiles this resource claims to conform to
security	Σ	0..*	Coding	Security Labels applied to this resource Binding: All Security Labels (extensible): Security Labels from the Healthcare Privacy and Security Classification System.
tag	Σ	0..*	Coding	Tags applied to this resource Binding: CommonTags (example): Codes that represent various types of tags, commonly workflow-related; e.g. "Needs review by Dr. Jones".
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
language		0..1	code	Language of the resource content Binding: CommonLanguages (preferred): A human language. Additional Bindings Purpose AllLanguages Max Binding
text		0..1	Narrative	Text summary of the resource, for human interpretation This profile does not constrain the narrative in regard to content, language, or traceability to data elements
contained		0..*	Resource	Contained, inline Resources
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
identifier	ΣC	0..*	Identifier	Identifies this organization across multiple systems
active	?!Σ	0..1	boolean	Whether the organization's record is still in active use
type	Σ	0..*	CodeableConcept	Kind of organization Binding: OrganizationType (example): Used to categorize the organization.
name	ΣC	0..1	string	Name used for the organization
alias		0..*	string	A list of alternate names that the organization is known as, or was known as in the past
telecom	C	0..*	ContactPoint	A contact detail for the organization Constraints: org-3
address	C	0..*	Address	An address for the organization Constraints: org-2
partOf	Σ	0..1	Reference(Organization)	The organization of which this organization forms a part
contact		0..*	BackboneElement	Contact for the organization for a certain purpose
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
purpose		0..1	CodeableConcept	The type of contact Binding: ContactEntityType (extensible): The purpose for which you would contact a contact party.
name		0..1	HumanName	A name associated with the contact
telecom		0..*	ContactPoint	Contact details (telephone, email, etc.) for a contact
address		0..1	Address	Visiting or postal addresses for the contact
endpoint		0..*	Reference(Endpoint)	Technical endpoints providing access to services operated for the organization
Documentation for this format

Terminology Bindings

Path	Status	Usage	ValueSet	Version	Source
Organization.meta.security	Base	extensible	SecurityLabels	📍4.0.1	FHIR Std.
Organization.meta.tag	Base	example	Common Tags	📍4.0.1	FHIR Std.
Organization.language	Base	preferred	Common Languages	📍4.0.1	FHIR Std.
Organization.type	Base	example	Organization type	📍4.0.1	FHIR Std.
Organization.contact.​purpose	Base	extensible	Contact entity type	📍4.0.1	FHIR Std.

Constraints

Id	Grade	Path(s)	Description	Expression
dom-2	error	Organization	If the resource is contained in another resource, it SHALL NOT contain nested Resources	contained.contained.empty()
dom-3	error	Organization	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource	contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Organization	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated	contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Organization	If a resource is contained in another resource, it SHALL NOT have a security label	contained.meta.security.empty()
dom-6	best practice	Organization	A resource should have narrative for robust management	text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children	hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both	extension.exists() != value.exists()
org-1	error	Organization	The organization SHALL at least have a name or an identifier, and possibly more than one	(identifier.count() + name.count()) > 0
org-2	error	Organization.address	An address of an organization can never be of use 'home'	where(use = 'home').empty()
org-3	error	Organization.telecom	The telecom of an organization can never be of use 'home'	where(use = 'home').empty()

This structure is derived from Organization

Summary

Mandatory: 1 element(2 nested mandatory elements)

Key Elements View

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Organization	C	0..*	Organization	A grouping of people or organizations with a common purpose Constraints: org-1
id	Σ	1..1	id	Logical id of this artifact
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
active	?!Σ	0..1	boolean	Whether the organization's record is still in active use
Documentation for this format

Constraints

Id	Grade	Path(s)	Description	Expression
dom-2	error	Organization	If the resource is contained in another resource, it SHALL NOT contain nested Resources	contained.contained.empty()
dom-3	error	Organization	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource	contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Organization	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated	contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Organization	If a resource is contained in another resource, it SHALL NOT have a security label	contained.meta.security.empty()
dom-6	best practice	Organization	A resource should have narrative for robust management	text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children	hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both	extension.exists() != value.exists()
org-1	error	Organization	The organization SHALL at least have a name or an identifier, and possibly more than one	(identifier.count() + name.count()) > 0

Differential View

This structure is derived from Organization

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Organization		0..*	Organization	A grouping of people or organizations with a common purpose
id		1..1	id	Logical id of this artifact
meta
source		1..1	uri	Identifies where the resource comes from
profile		1..*	canonical(StructureDefinition)	Profiles this resource claims to conform to
Documentation for this format

Snapshot View

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Organization	C	0..*	Organization	A grouping of people or organizations with a common purpose Constraints: org-1
id	Σ	1..1	id	Logical id of this artifact
meta	Σ	0..1	Meta	Metadata about the resource
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
versionId	Σ	0..1	id	Version specific identifier
lastUpdated	Σ	0..1	instant	When the resource version last changed
source	Σ	1..1	uri	Identifies where the resource comes from
profile	Σ	1..*	canonical(StructureDefinition)	Profiles this resource claims to conform to
security	Σ	0..*	Coding	Security Labels applied to this resource Binding: All Security Labels (extensible): Security Labels from the Healthcare Privacy and Security Classification System.
tag	Σ	0..*	Coding	Tags applied to this resource Binding: CommonTags (example): Codes that represent various types of tags, commonly workflow-related; e.g. "Needs review by Dr. Jones".
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
language		0..1	code	Language of the resource content Binding: CommonLanguages (preferred): A human language. Additional Bindings Purpose AllLanguages Max Binding
text		0..1	Narrative	Text summary of the resource, for human interpretation This profile does not constrain the narrative in regard to content, language, or traceability to data elements
contained		0..*	Resource	Contained, inline Resources
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
identifier	ΣC	0..*	Identifier	Identifies this organization across multiple systems
active	?!Σ	0..1	boolean	Whether the organization's record is still in active use
type	Σ	0..*	CodeableConcept	Kind of organization Binding: OrganizationType (example): Used to categorize the organization.
name	ΣC	0..1	string	Name used for the organization
alias		0..*	string	A list of alternate names that the organization is known as, or was known as in the past
telecom	C	0..*	ContactPoint	A contact detail for the organization Constraints: org-3
address	C	0..*	Address	An address for the organization Constraints: org-2
partOf	Σ	0..1	Reference(Organization)	The organization of which this organization forms a part
contact		0..*	BackboneElement	Contact for the organization for a certain purpose
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
purpose		0..1	CodeableConcept	The type of contact Binding: ContactEntityType (extensible): The purpose for which you would contact a contact party.
name		0..1	HumanName	A name associated with the contact
telecom		0..*	ContactPoint	Contact details (telephone, email, etc.) for a contact
address		0..1	Address	Visiting or postal addresses for the contact
endpoint		0..*	Reference(Endpoint)	Technical endpoints providing access to services operated for the organization
Documentation for this format

Terminology Bindings

Path	Status	Usage	ValueSet	Version	Source
Organization.meta.security	Base	extensible	SecurityLabels	📍4.0.1	FHIR Std.
Organization.meta.tag	Base	example	Common Tags	📍4.0.1	FHIR Std.
Organization.language	Base	preferred	Common Languages	📍4.0.1	FHIR Std.
Organization.type	Base	example	Organization type	📍4.0.1	FHIR Std.
Organization.contact.​purpose	Base	extensible	Contact entity type	📍4.0.1	FHIR Std.

Constraints

Id	Grade	Path(s)	Description	Expression
dom-2	error	Organization	If the resource is contained in another resource, it SHALL NOT contain nested Resources	contained.contained.empty()
dom-3	error	Organization	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource	contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Organization	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated	contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Organization	If a resource is contained in another resource, it SHALL NOT have a security label	contained.meta.security.empty()
dom-6	best practice	Organization	A resource should have narrative for robust management	text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children	hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both	extension.exists() != value.exists()
org-1	error	Organization	The organization SHALL at least have a name or an identifier, and possibly more than one	(identifier.count() + name.count()) > 0
org-2	error	Organization.address	An address of an organization can never be of use 'home'	where(use = 'home').empty()
org-3	error	Organization.telecom	The telecom of an organization can never be of use 'home'	where(use = 'home').empty()

This structure is derived from Organization

Summary

Mandatory: 1 element(2 nested mandatory elements)

Other representations of profile: CSV, Excel, Schematron
