Specification

Page standards status: Informative

This section of the implementation guide (IG) defines the specific conformance requirements for systems wishing to conform to this US SAFR Reporting IG. The bulk of it focuses on evaluating facility data against measure criteria and submitting those data to MeasureReport Recipient (NHSN), though it also provides guidance on privacy, security, and other implementation requirements.

Pre-reading

Before reading this formal specification, implementers should first familiarize themselves with two other key portions of the specification:

  • The Actors and Use Cases pages provide context for the intent and general process flow of this formal specification, as well as details on the various actors involved.

Conventions

This implementation guide (IG) uses specific terminology to flag statements that have relevance for the evaluation of conformance with the guide:

  • SHALL indicates requirements that must be met to be conformant with the specification.

  • SHOULD indicates behaviors that are strongly recommended (and which may result in interoperability issues or sub-optimal behavior if not adhered to), but which do not, for this version of the specification, affect the determination of specification conformance.

  • MAY describes optional behaviors that are free to consider but are not a recommendation for or against adoption.

Must Support

The following rules regarding Must Support elements apply to all Profiles in this guide. The Must Support definitions are not inherited from other IGs, even for profiles in this guide derived from another guide.

Sender:

  • If the data element is available in through the Data Source, the data element SHALL be provided (either through submission or response to a query) for measure calculation or risk adjustment.
  • If the sender does not capture/store the data, the data are not available, or sharing of the data is not authorized, the system SHOULD NOT send the element if the element is not marked as mandatory (lower cardinality of 0).

Receiver:

  • The receiver SHALL be capable of processing resource instances containing must-support data elements without generating an error or causing the application to fail.
  • The receiver SHALL be able to process resource instances containing must-support data elements asserting missing information (data absent reason extension).

Profiles

This specification makes significant use of FHIR profiles and terminology artifacts to describe the content to be shared as part of measure report submissions.

The full set of profiles defined in this IG can be found by following the links on the Artifacts page.

Reporting Scenarios

The following reporting scenarios use the Actors defined on the Actors and Use Cases pages.

Push to MeasureReport Recipient (NHSN)

In this scenario both the Data Source and digital Quality Measure (dQM) evaluation engine reside at the reporting facility, and may be the same system (e.g., an EHR that performs it’s own internal measure evaluation). The dQM Evaluation Engine first retrieves the latest FHIR measures and related resources from the measure repository and extracts the data requirements for each measure. The dQM Evaluation Engine and queries the Data Source for data that it will evaluate against a measure and prepares Bundle containing MeasureReport and supporting resources, then sends it to the MeasureReport Recipient (NHSN).

In this scenario the dQM Evaluation Engine SHALL perform a FHIR POST or PUT to push the measure report bundle to the MeasureReport Recipient (NHSN).

Healthcare FacilityNHSNData Source (EHR)dQM Evaluation EngineOther NHSN System(out of scope for this IG)Measure SourceMeasureReport Recipient(2)Query Data Source(FHIR or other API)(1)Retrieve Measure Bundle(3)Submit MeasureReport Bundle(4)Forward to NHSN Systems

  1. Retrieve Measure Bundle: The dQM Evaluation Engine uses an HTTP GET against the measure repository for an USSafrMeasureBundle containing a CQFMContinuousVariableMeasure and related resources. The exact Bundle(s) to retrieve is determined out of band by the facility and MeasureReport Recipient (NHSN) during onboarding and subsequent discussions. After retrieving the Bundle, the dQM evaluation engine parses the contents to determine which resources are needed from the Data Source, then proceeds to step 2.

  2. Query Data Sources:

  3. Submit MeasureReport Bundle The dQM Evaluation Engine uses an HTTP POST to submit the SafrMeasureReportBundle to the MeasureReport Recipient. The MeasureReport Recipient validates the Bundle and proceeds to load the data into other MeasureReport Recipient (NHSN) systems (details of such systems are out of scope for this IG).

  4. Forward to MeasureReport Recipient (NHSN) Systems: The MeasureReport Recipient (NHSN) forwards the validated MeasureReport Bundle content to other back-end MeasureReport Recipient (NHSN) systems (details of such systems are out of scope for this IG).

Pull Direct from Healthcare Facility

In this scenario, both the Digital Quality Measure (dQM) Evaluation Engine and the MeasureReport Recipient reside within an Public Health Agency (NHSN) controlled environment, and may be the same system. The dQM Evaluation Engine first retrieves the latest FHIR measures and related resources from the measure repository and extracts the data requirements for each measure. The dQM Evaluation Engine queries the Data Source for data that it will evaluate against a measure and prepares Bundle containing MeasureReport and supporting resources. In this scenario the Data Source SHALL have a FHIR API that at a minimum provides read access to all US Core profiles. Some measures may require additional FHIR resources beyond US Core, such as MedicationAdministration.

Healthcare FacilityNHSNData Source (EHR)dQM Evaluation EngineMeasure SourceMeasureReport Recipient and Other NHSN Systems(2)Query Data Source(1)Retrieve Measure Bundle(3)Submit MeasureReport Bundle

  1. Retrieve Measure Bundle: The dQM Evaluation Engine uses an HTTP GET against the measure repository for an USSafrMeasureBundle containing a CQFMContinuousVariableMeasure and related resources. The exact Bundle(s) to retrieve is determined out of band by the facility and MeasureReport Recipient (NHSN) during onboarding and subsequent discussions. After retrieving the Bundle, the dQM evaluation engine parses the contents to determine which resources are needed from the Data Source, then proceeds to step 2.

  2. Query Data Sources:

  3. Submit MeasureReport Bundle The dQM Evaluation Engine uses an HTTP POST to submit the SafrMeasureReportBundle to the MeasureReport Recipient. The MeasureReport Recipient (NHSN) validates the Bundle and proceeds to load the data into other backend systems (details of such systems are out of scope for this IG).

Pull from States then send to MeasureReport Recipient (NHSN)

In this scenario, a state/jurisdiction retrieves the measure bundle from NHSN and queries for data for aggregation from one or more healthcare facility before evaluating and submitting the MeasureReport to the Measure Recipient on behalf of the facilities.

In this scenario the state/jurisdiction SHALL have a FHIR API that at a minimum provides read access to all US Core profiles. Some measures may require additional FHIR resources beyond US Core, such as MedicationAdministration.

Healthcare Facility OneHealthcare Facility TwoHealthcare Facility ThreeHealthcare Facility FourJurisdiction OneJurisdiction TwoNHSNData Source (EHR)Data Source (EHR)Data Source (EHR)Data Source (EHR)dQM Evaluation EngineMeasureReport RecipientData AggregatordQM Evaluation EngineMeasureReport RecipientMeasureReport Recipient and Other NHSN SystemsMeasure Source(2)Query Data Source(2)Query Data Source(2)Aggregate Datavia FHIR or other API(1)Retrieve Measure Bundle(3)Submit MeasureReport Bundle(2)Query Data Source(2)Query Data Source(1)Retrieve Measure Bundle(3) Submit MeasureReport Bundle(4)Submit MeasureReport Bundle(4)Submit MeasureReport Bundle

  1. Retrieve Measure Bundle: The state/jurisdiction dQM Evaluation Engine uses an HTTP GET to retrieve the USSafrMeasureBundle containing a CQFMContinuousVariableMeasure and related resources from the measure repository. The exact Bundle(s) to retrieve is determined out of band by the facility and MeasureReport Recipient (NHSN) during onboarding and subsequent discussions. After retrieving the Bundle, the dQM evaluation engine parses the contents to determine which resources are needed from the Data Source, then proceeds to step 2.

  2. Query Healthcare Facility: The state/jurisdiction query each healthcare facility EHR for data aggregation via FHIR API.

  3. Submit MeasureReport to MeasureReport Recipient The dQM Evaluation Engine uses an HTTP POST to submit the SafrMeasureReportBundle to the MeasureReport Recipient (NHSN). The MeasureReport Recipient (NHSN) validates the Bundle and proceeds to load the data into other backend systems (details of such systems are out of scope for this IG).
