Use Cases and Workflows

Page standards status: Trial-use

Business Need and Use Cases

The section identifies the business needs and specific user stories for DAPL FHIR IG. The same set of business needs are applicable to the DARTS IG.

Use Cases for Deidentification

Use Case 1: Federal Agency Reporting:

Currently there are many reporting programs across the US where healthcare organizations submit data to state and federal agencies in aggregate form. While these aggregate reports meet current mandates, there is a desire to obtain more detailed line-level information instead of aggreate data. However, in many instances the federal agency may not have the authorities necessary to receive PII/PHI data and hence requires the data to be deidentified in order to receive more granular data. The following are the examples of such reporting

• UDS reporting from Federally Qualified Health Centers (FQHCs) to HRSA

Use Case 2: Clinical Research Reporting:

There are many research programs that require researchers to track a specific disease and treatment. For example, a researcher studying diabetes outcomes will require labs, medications, approximate timelines but does not require the identity of the individual. This requires PII/PHI to be deidentified and then submitted to the researcher.

Use Case 3: AI/ML Model to predict hospital readmissions

As the use of AI/ML models increase new models are being created which need data to predict outcomes such as the number of hospital readmissions expected for the month. These AI models do not require identifiable information but require the clinical encounter information and the context of these encounters which can be achieved by deidentifying the information before submitting to the AI model.

Use Case 4: Quality Improvement Initiatives

Quality improvement initiatives or programs that are measuring treatment effectiveness, patient outcomes require line level granular data without identity and the patient information has to be deidentified before submission to these quality improvement programs.

Use Cases for Anonymization

Use Case 1: Federal Agency published disease prevalance statistics:

Federal Agencies collect data from the states and perform analysis and publish common data sets such as disease prevalence statistics that is an open data set and can be used by the public. This requires anonymization of the data without reidentification risk.

Use Case 2: Datasets released to global researchers:

Hospitals, Aggregators, Agencies may wish to release certain datasets to global researchers to enable innovations and studies. These data sets cannot have any reidentification risk and will require anonymization of the data before making the data set and releasing it to the global research community.

Use Case 3: Publications in Journals

Publishing of data in journals require only aggregated insights and do not require granular PHI/PII details. This can be achieved using anonymization of the data sets without risk of reidentification for studies and then publications.

Use Case 4: Data Sharing with 3rd Party Analytics Vendors

Many entities share data with 3rd party analytics vendors to examine population analytics, trends, create interventions based on analytics etc. These situations do not require PHI/PII and the data set should avoid reidentification and hence anonymized data is required to be submitted to these vendors for analytics.

Explanation of Psuedonymized, Deidentified and Anonymized data

This section repeats some of the definitions from the DARTS IG.

Psuedonymized data

Psuedonymization is the process by which PII/PHI can no longer be attributed to a specific patient without the use of additional information. Psuedonymization does not remove PII/PHI but rather it translates the information into a token. Psuedonymized data is still considered PII/PHI as it can be reidentified with a mapping key.

For e.g, Patient John Doe may be called as Patient_12345 which is produced by using some kind of mapping key or algorithm and is always linked back to John Doe.

Deidentified data

Under the HIPAA privacy rule deidentified information is “Health information that does not identify an individual and with respect to which there is no reasonable basis to believe that the information can be used to identify an individual.” - 45 CFR §164.514(a)

Alternately, Deidentification is the process of removing or transforming identifiers so that an individual cannot be readily identified, with a very low risk of re-identification.

NOTE: There are deidentification use cases which may require reidentification and are reidentification is performed in controlled circumstances.

For e.g, Patient John Does data will not have any patient identifier or name.

According to HHS Safe Harbor Guidance 18 different Patient related attributes should be removed for the data to be called deidentified data. These attributes that need to be removed are specified in the HHS Safe Harbor Deidentification Standard and are listed here for convenience.

A) Names B) Addresses and geographic locations C) Dates D) Telephone numbers E) Fax numbers F) Email Addresses G) Social Security numbers H) Medical Record numbers I) Health plan beneficiary numbers J) Account numbers K) Certificate/license numbers L) Vehicle identifiers and license plate numbers M) Device Identifiers and serial numbers N) Web Universal Resource Locators (URLs) O) Internet Protocol (IP) Addressess P) Biometric identifiers including finger and voice prints Q) Full-face photographs and comparable images R) Any other unique identifying characteristic, code of the individual

Reidentification of deidentified information

During the deidentification process, the assignment of a unique code to the set of deidentified health information to permit re-identification is the prescribed method of reidentifying information. The entity that is submitting the deidentified information is responsible to protect the reidentified information as per organization, local, state and federal policies.

Anonymized data

Anonymization is the irreversible process of transforming data so that individuals cannot be identified by any reasonably likely means, now or in the future. In other words, data is anonymous if individuals are not identifiable, taking into account all means “reasonably likely” to be used to identify the person.

For e.g, Consider John Doe a male patient with an age of 56 with diabetes needs to be included in a specific data set. John Doe's record would be included in a data set without any identifying information such as names, date of birth. Instead John Doe's record would be included in an age group between 50 and 60 consisting of many individuals with Diabetes who are males. Location information would be generalized from a specific address to a large geographical area such as one or more states or the entire country. The more number of individuals with similar characteristics the lower the risk of identification. Rare diseases would be combined into a group such as "Other" to avoid identification.

The above definitions are used to create the necessary profiles to represent the data and the conventions are defined below.

DAPL IG Profile Definitions and Conventions

This section clarifies the basic profile definitions specified in the IG and provides the context in which they need to be used.

Profiles common to Deidentification and Anonymization

Many of the profiles that are defined in the IG are common to both deidentification and anonymization. For e.g, profiles related to Diagnosis, Procedures etc.

These profiles will be named as dapl-[Resource/Profile Name]" where the Resource Name would be "Procedure or MedicationRequest etc".

Sometimes instead of Resource name the IG uses a profile name which is unique. For e.g, lab-observation, income-observation where the Observation resource is profiled multiple times for different purposes.

These profiles which dont have the words "deidentified" or "anonymized" can be used for representing both Deidentified data and Anonymized data.

Profiles used only to represent Deidentified data

Some profiles are to be used only to represent deidentified data which carry certain information about age, sex, race, ethnicities, locations with a low risk of reidentification.

These profiles will be named as dapl-deidentified-[Resource/Profile Name]" where the Resource Name would be "Patient" or "Encounter".

Profiles used only to represent Anonymized data

Some profiles are to be used only to represent anonymized data which eliminates/generalizes age, sex, race, ethnicities, locations further (beyond deidentified profiles) to eliminate reidentification risk

These profiles will be named as dapl-anonymized-[Resource/Profile Name]" where the Resource Name would be "Patient" or "Encounter".

Identification Risk

The risk of identification when using the above profiles/data structures has to be ascertained by the healthcare organization releasing or providing the data based on the use case. The following are links that provide valuable industry regulations and guidance for risk assessments

• HHS HIPAA Deidentification Guidance
• NIST Guidance
• NIST IR 8053 for Deidentification
